Bonfiglioli Squalo 2000 (NEW)

Description:

Structure made of STRENX 700 and HARDOX 500
230 HP Diesel motor
Fully automatic and operated by PLC
Remote Control
Cut cycle for High speed version 1 cut per 30 seconds
Minimal footprint required
Adjustable cutting lengths (manually by pin)
Great density achieved by the pressure of the lateral flippers and blank holders on the material prior to be sheared.
1 man operation – the lowest running costs in the market
No need to downsize the material with alligator shears or torch thanks to its extended jib and hopper capacity.

Dimensions
Main Structure Strenx 700 & Hardox 500
Length 8625 mm
Width 2550 mm
Height 3260 mm
Weight 67 tons

Working Cycle
Automatic cycle 30 seconds (fast cut option)
Remote control Yes
Processing capacity (tons/hr.) 22 – 25 t/hr
Internal Box Width 2300 mm
Shear head force 1450 t
Shear head throat opening 760 (H) X 1.290 (W) mm

Cutting Length
Shortest Length of cut 450 mm
Adjustable Cutting lengths 450/640/830/1.020 mm
Feeding hopper width 2300 mm
